Monads in Category Theory for Laymen
Chinese version: here
I’m not going to discuss how to use monads.
If you want to know how they’re used, you should know its various instances first, such as List
, Maybe
, Writer
, State
, etc.
What am I going to talk about in this article then?
You should know there are 3 coherence laws since you knew what monads are, but they might seem like black magic for most of you (including myself).
What I’m going to do is to show that those 3 laws are “obvious” in some sense without actually teaching you the whole category theory behind it.
The first problem is that there are several different but equivalent kinds of definition of monads, and Haskell adopts the weirdest one.
I’m going to introduce an alternative definition that appears more commonly in category theory.
Let me mention that there’s such a function in the module Control.Monad
:
(>=>) :: Monad m => (a > m b) > (b > m c) > (a > m c)
Why mentioning this operator?
The (simplified) definition of the Monad
class in Haskell is:
class Monad m where
return :: a > m a
(>>=) :: m a > (a > m b) > m b
But the below definition is equivalent to the above.
class Monad m where
return :: a > m a
(>=>) :: (a > m b) > (b > m c) > (a > m c)
The truth that both of them can define one another is left as an exercise to the reader.
The 3 laws according to the latter definition would be：
return >=> f = f
f >=> return = f
(f >=> g) >=> h = f >=> (g >=> h)
The spoiler is that the 3 laws below are those for monoids.
mempty <> x = x
x <> mempty = x
(x <> y) <> z = x <> (y <> z)
Why mentioning monoids?
You can see that the laws for >=>
are actually the same as those for monoids!
Turn f
, g
, h
into a
, b
, c
, resp., return
into mempty
,and >=>
into <>
then you get the laws for monoids.
The first law is called the coherence of left identity, meaning adding nothingness to the left doesn’t change the result.
The second is the one for right identity, meaning adding to the right also does nothing.
The final one is the law of associativity, which says that the order of applying the operation is not important, and is a generalization of the associativity for the sum and the product you learned in elementary school.
The only difference is that a <> b
is always defined for all monoids a
and b
.
On the other hand, the arguments of >=>
are not simple types such as Int
or [Bool]
but a function type a > m b
.
They have some internal structure namely a
and b
.
>=>
is not always defined if you pick one a > m b
and one c > m d
randomly
The compiler could simply pop out a compile error.
In fact, it only compiles when b ~ c
.
So return
and >=>
does not form a monoid
, but something that is more stronglytyped, in that the return type of the first function argument have to do something with the input type of the second function argument.
And those “stronglytyped” monoids actually have a name in math, namely, Categories.
Now introducing the definition the mathmaticians love even more but might be harder for dummies.
I assume you already knew what Functor
s are.
You probably also knew that all Monad
s are Functor
s
I’m going to define Monad
s as Functor
s with extra constraints below:
class Functor m => Monad m where
return :: a > m a
join :: m (m a) > m a
How can you derive the previous 2 kinds of definition from this one?
If you have something of type a > f b
and something of type b > f c
in which f
is just a Functor
, after applying with first function, you can map
the elements of the result of it with the second function.
You would get an f (f c)
from an a
then.
The problem is that repeating concatenation makes the result type more nested (more layers of f
), and it really isn’t convenient for us programmers.
Can’t I collapse them into one layer?
Of course you can with the operation join
because that’s exactly what join
does!
Now there’s a trick notationwise.
We can just look at the Functor
s of kind * > *
themselves and ignore their underlying type arguments.
For the sake of brevity, I use some strange syntax in which the type of join
is written mm > m
.
it merges 2 sibling (actually nested) Monad
s into one.
But how do I write the type of return
in that strange kind of syntax?
You should know there’s a Functor
that does nothing called Identity
, and Identity a
is equivalent to a
because Identity
is just an empty effect.
I abbreviate Identity
as I
below.
The type of return
is then equivalent to I a > m a
.
Using that strange notation, it’s I > m
.
It’s time for introducing Monad
s again.
They are Functor
s equipped with return
and join
, satisfying the following 3 laws, respectively:

I can add an
I
to the left of anm
(actually wrapping them
inside), and then transform it into anm
usingreturn
.
How is it possible?
Thinking in the way of the strange syntax, return has typeI > m
, and what it does is exactly transforming anI
into anm
!
Now we have 2 layers ofm
s, that is,mm
.
I can join them together, transforming that intom
again.
The law is that transforming back and forth is the same as doing nothing.
I can add an
I
to the right of anm
.
Thinking in the Haskell way, you justmap
elements of typea
insidem
to the ones of typeI a
.
Thinking in the strange syntax, you simply add an adjacentI
on the right.
I can turnmI
intomm
again usingreturn
, which should also be the same as doing nothing afterjoin
ing it into a singlem
.
If there are 3 layers of
m
, that is,mmm
, there are 2 different ways tojoin
them twice into anm
.
Onejoin
s the left 2m
s first, the otherjoin
s the right ones first.
Nonetheless, ordering of the operations shouldn’t affect the result.
But they are the 3 laws of Monoid
s!
The first is the left identity: adding nothingness to the left doesn’t change anything.
The second is the right identity: you can also add nothingness to the right.
Finally the associative law, the order of doing operations isn’t important.
Doesn’t it seem obvious enough now?
Therefore,
A monad is just a monoid in the category of endofunctors, what’s the problem?
